Pumping And Power Dashboard

This is a beta version of the Pump and Power Dashboard. It is best viewed on desktop or a laptop. We are working to optimize the page for mobile. Customers can test the dashboard and provide feedback to SWBNO via email at outreach@swbno.org. The page will continue to evolve as we add more capabilities and receive user feedback.

Turbine 4 is unavailable.

Pump and Power Status

Equipment Status as of July 2, 2024
turbine icon
Turbine 5 and 6 available for use.
emd icon

4 of 5 EMDs are available for use.

pump icon

90 of 99 Major Pumps are available.

25Hz Power Generation Capacity

Our older drainage pumps require 25Hz power. The modern standard is 60Hz. Turbine 4, Turbine 5 and our EMDs (back-up generators) generate 25Hz power. We also have Frequency Changers that convert 60Hz power provided by Entergy to 25Hz. The graphic below shows how much 25Hz power we can currently generate with the sources available.

49 MW

Currently Available

44MW of power needed at peak demand

The Drainage Pump Station Status map is best viewed in full-screen mode (and horizontally on mobile). Show Map Fullscreen



Full Pumping and Power Status

Major Drainage Pumps: 90 of 99 Major Drainage Pumps Available For Use

  • DPS 6 on Orpheum Ave: I pump out of service undergoing routine maintenance.
    • 12 additional drainage pumps available at this station + 2 constant duty pumps
  • DPS 3 on Florida Ave near Hwy 90: D Pump out of service due to replacement of bearing housing unit.
    • 4 additional drainage pumps available at this station + 4 constant duty pumps
  • DPS 10 at Haynes Blvd. and Shubrick Ave. at Citrus Canal: No. 1 Pump out of service due to refurbishment of pump.
    • 3 additional drainage pumps available at this station
  • DPS 13 near Tall Timbers Algiers: No. 4 Pump on standby for emergency use only.
    • 5 additional drainage pumps available at this station + one constant duty pump
  • DPS 14 at Hayne Blvd and Jahncke Rd: No. 3 and No. 4 Pump out of service due to mechanical repairs
    • 2 additional drainage pumps available at this station
    • Drainage in this area can be addressed via DPS 10, DPS 16 and DPS Dwyer via the Morrison Canal
  • DPS 15 near Intracoastal Waterway and Industrial Pkwy: No. 1 Pump out of service due to repairs to a gearbox.
    • 2 additional drainage pumps available at this station
  • DPS 17 near Florida Ave. and Peoples: Pumps A & D out of service due to issues with the electric motors.
  • DPS 18 near Maxent Canal and Michoud Bayou: No. 1 Pump out of service due to mechanical repairs. A portable pump has been installed to provide temporary pumping capacity as needed
    • 1 additional drainage pumps available at this station

Underpass Stations:

All underpass pumps in service.

Click here for an overview and an interactive map of our drainage system.


Power Status:

  • Turbine 4 unavailable.
  • SWBNO crews anticipated bringing T4 back online the week of July 1. However, after replacing the bearings and conducting testing on the turbine, we identified further improvements needed to fully rehabilitate the machine, which was orginally built in 1915. We anticipate receiving the necessary additional parts after the July 4th holiday. Contractor personnel and SWBNO staff will be on standby to continue testing once the parts arrive.
  • Turbine 5 available for use.
  • Turbine 6 available for use.
  • EMDs #2, #3, #4 and #5 are in service.   EMD #1 is offline due to a radiator leak.

EMDs are back-up generators that provide 25Hz power.

  • Frequency Changer #1 at Carrollton Frequency Changer Facility is available for use.
  • Frequency Changer #2 at Carrollton Water Treatment Plant available for use.
  • Frequency Changer #3 at Station D is available for use.
  • Plant Frequency Changer at Carrollton Water Plant out of use due to an electrical issue
  • Frequency Changer # 4 at Station D available for use.
  • Frequency Changer #3 at Algiers Water Treatment Facility available for use.

Frequency changers convert modern 60Hz power generated by T6 and Entergy into the 25Hz power.
